AVC Z7UB301 AMD Reference Athlon64 Heatsink Review
AVC Z7UB301 AMD Reference Athlon64 Heatsink Review
  80%
Abstract: The AVC Z7UB301 heatsink is one of the first stock Socket 754 heatsinks AMD shiped with its processors, and it is currently used with most Socket 939 Athlon64 CPU models too.

 Manufacturer  Category  Published  Author
AVC   Cooling / Heatsinks   Nov 28, 2005   Max Page

Home > Reviews > Page: Final Heatsink Temperature Comparisons
FrostyTech.com Mk.II Synthetic Thermal Heatsink Test Results
Results based on readings from a 38x38mm copper interface die with 125W heat load on the Mk.II Test Platform. Thermal Test values for each heatsink were calculated by determining the rise over ambient temperature at time of test. Information on Frostytech's test methodology is available here.
Socket 939/940/754 compatible CPU heatsinks
manufacturer: model no.: *fan speed: 125w thermal test (°c) noise level (dba)

Gigabyte G-Power Pro high 18.6 71.9
Coolermaster Hyper6 high 20.5 54.7
Thermaltake Venus 12 high 21.7 68.1
ASUS Starice high 22.8 67.4
Coolermaster Aquagate Mini high 23.2 59.2
Thermaltake Polo 735 high 23.4 68.0
Cooljag SFO-H high 23.6 60.6
Alpha PAL-8150 23.7 58.9
Zalman CNPS9500LED (clip parallel) high 23.8 50.3
AVC Z7U3301001 (stock 939) high 24.6 59.9
Gigabyte 3D Cooler-Ultra high 24.8 63.0
Scythe Shogun high 26.0 45.9
EKL V8 high 26.3 57.5
Arctic Cooling Freezer 64 Pro 26.9 50.9
Gigabyte 3D Rocket-Pro high 26.9 56.7
Gigabyte 3D Cooler-Pro high 27.0 62.5
Gigabyte 3D-Rocket 28.9 50.7
Vantec Mach1 high 29.2 56.9
CoolJag SFO-D(18SC) 29.6 64.0
Zalman CNPS7000A-Cu high 30.3 45.2
Dynatron SK-V24 30.3 56.4
Verax Quattro 1 high 30.7 55.4
Zalman CNPS7000-Cu high 31.0 45.2
Coolermaster Hyper48 31.7 43.6
Scythe Kama SCKK1000 31.9 47.5
Scythe Samurai SCSM1000 high 32.1 51.6
Zalman CNPS7000B-CU high 32.3 44.9
Thermaltake Silentboost K8 32.3 49.7
AVC Z7U3301001 (stock 939) low 32.6 44.2
Jetart JAX801 33.2 53.5
Dynatron A22 34.5 44.5
nPowertek NPH K8-1 34.6 52.2
Ajigo MF043-044 (stock 754) 35.0 45.4
Arctic Cooling Silencer 64 Ultra TC 37.5 55.5
Gigabyte NeonCooler 8-BL 37.7 42.0
Titan TTC-K8ATB/825/SC 38.7 63.1
Evercool K802-715 42.1 51.5
Evercool Magic Cooler 46.6 55.5
125w thermal test (°c) noise level (dba)
*heatsinks are ranked according to the 125w thermal test results column (rise over ambient temp.). low temperatures with low noise levels are considered best. for reference heatsinks with variable-speed fans, only the high speed (12v) fan test result is included in the comparison sheet; more detailed results reside in each specific heatsink review.

At its highest fan speed of 5400RPM, the AVC Z7UB301 heatsink performs very well indeed. According to the thermal test results from the FrostyTech Mk.II Synthetic Test Platform which applies a 125W heat load to the heatsink, the AVC Z7UB301 maintained a rise above ambient temperature of 24.6°C at its best fan speed. The noise level was nearly 60 dBA in that case however.

When running with a more conservative fan speed, noise levels dropped to about 44 dBA and temperatures rose to a rise above ambient temp. of 32.6°C - pretty good actually. The temperature sensitive fan utilized on the AVC Z7UB301 heatsink certainly gives it the potential to be both a great performing heatsink and a lower noise one as well.

Considering these results, it is clear that AMD has provided socket 754/939/940 Athlon64 users with very capable heatsink. The AVC Z7UB301 is designed to cool only as much as necessary, which leaves us wishing there were a way to manually control the fan speed. In any case, it is comforting to note that there are quite a few third-party heatsinks which perform poorer than the AMD reference AVC Z7UB301 heatsink at its quietest, and most surprisingly with higher noise levels too.
